3M 7010493156 633AH Wheel, 5 in Dia Wheel x 1-3/4 in THK Wheel, 1-1/4 in Center Hole, D320 Grit, Diamond Abrasive

3M, 7010493156, Wheel, Series: 633AH, 5 in Wheel Diameter, 1-3/4 in Wheel, 1-1/4 in Center Hole, D320 Grit, Diamond Abrasive, 2200 to 3400 sfpm Fluting, 4500 to 6500 sfpm Gashing, 4500 to 5500 sfpm OD and End Work Maximum, Resin Bond, Applicable Materials: Carbide, Non-Ferrous Metals, PCD, Cermet's and Polycrystalline CBN/Diamond (PCBN), Wheel Type Number: 11V9

The 3M diamond resin bond wheel 633AH is a general purpose wheel designed for the production and re-sharpening of tungsten carbide tipped saw blades. This wheel offers high material removal rates and good form retention. Designed for precision resin bonded diamond wheels are designed for high performance when grinding on materials such as tungsten carbide. The 3M diamond resin bond wheel 633AH line is specifically designed for the production and re-sharpening of tungsten carbide tipped saw blades. This application requires the highest level of quality which the 3M diamond resin bond wheel 633AH provides. High quality bonding these super abrasive wheels also use a resin bonding which are specially designed to resist thermal and chemical deterioration, which can occur during high speed grinding. This N hardness rated bond delivers high material removal rates when grinding materials such as tungsten carbide. The wheel is designed for dry grinding. The right wheels for the job 3M provides a broad portfolio of super abrasive wheels that cover the full range grinding applications on hard to grind materials. These wheels are available in a variety of sizes, shapes, core materials and arbor holes custom bore to fit customer specifications. From short runs and re-sharpening to "lights-out" and long production runs, 3M has the wheel design to meet your needs.
