3M 7000133275 Insulated Butt Connector, 22 to 18 AWG Conductor, 1 in L, Butted Barrel, Copper/Nylon, Red

3M, 7000133275, Butt Connector, Insulated, 22 to 18 AWG Conductor, 1 in Length, Butted Barrel, 0.07 in ID x 0.25 in L Barrel, 600 VAC, -40 to 221 deg F, Copper/Nylon, Red, 0.145 in OD Dimensions

Each 3M Scotchlok Butt Connector features a flared nylon sleeve that resists damage from abrasions and provides a positive grip for a more secure connection. The stepped design makes crimping easier, and the red color-coding is ideal for easy wire size identification. This connector has a brass covered butted-seam barrel that guides wires into position to deliver proper electrical contacts and provide stress relief at the point of insulation. These connectors are UL Listed, CSA Certified and RoHS 2011/65/EU Compliant for additional safety assurance.
